DXD series automatic liquid filling and packaging machine adopts intelligent numerical control system, imported stepping motor bag pulling mechanism and advanced photoelectric system with stable performance. It is widely used in medicine, food, chemicals, pesticides, seeds and other materials of small bag packaging (liquid, particles, powder, sauce).
Packaging application: small pouch sauce, chili oil, oil bag, jam, instant noodles seasoning bag, tomato sauce, sushi soy sauce bag, small bag mustard, sauce bag and other condiments and chemicals packaging.
Technical Parameters:
| Item | Parameters |
| Power supply | 220 50/60Hz |
| Power | 1.5KW |
| Filling speed | 20-50 bags/second |
| Filling style | Back seal |
| Size of bag | L:20-240m W:30-200mm |
| Size for machines | 625x750x1550mm/185kgs |
| Packing material | Paper/polyethylene, BOPP/polyethylene, aluminum foil/polyethylene, polyester/aluminum plating/polyethylene, nylon/polyethylene, non-woven fabric, filter paper and other composite materials |
Technical features:
1. Button switch with full digital display. Stable and reliable operation.
2. Computer control. The system uses the stepper motor subdivision technology with high bag making accuracy. The the error is less than 1 mm.
3. Automatic color tracking, intelligent elimination of false color, automatic positioning and fixed length of packaging bag.
4. Double heat sealing temperature control, intelligent temperature control, good thermal balance to ensure the quality of sealing, suitable for a variety of packaging materials.
5. Intelligent photoelectric color calibration position control system.
6. Various bag type: pillow sealing, standing type ,punching etc.
Main USES:
The automatic liquid filling and packaging machine is suitable for paste and liquid packaging, including sesame paste, bean paste sauce, chili oil, liquid Chinese medicine, chemical raw materials and other products with the function of automatically filling the material into the pouch, automatic sealing, automatic cutting, etc. It has the advantages of high speed, accurate, economy and practicality.
